| Parameter (参数名称) | Specification (规格数据) |
| Output (输出方式) | Fiber-optic coupling (光纤耦合) |
| Laser wavelength (激光波长) | 980nm + 1470nm |
| Output Power (输出功率) | 30W + 9W |
| Pulse width (脉宽) | 15ms — 60ms |
| Frequency (频率) | 1-9Hz |
| Aiming Beam (指示光/瞄准光) | 650nm |
| Mode (工作模式) | Pulse mode / Continuous mode (脉冲模式 / 连续模式) |
| Input (输入电源) | AC: 100-240V, 50/60Hz |
| Operation interface (操作界面) | 8.0 inch (8.0 英寸) |
| language (语言) | English or OEM (英文或定制) |
| Length of Fiber (光纤长度) | 3m |
| Fiber core diameter (光纤芯径) | 400µm |
| Cooling (冷却方式) | Air cooling (风冷) |
| Net/Gross weight (净重/毛重) | 5KG / 13KG |
| Machine Dimensions (机器尺寸) | 360mm * 330mm * 205mm |
| Flight case Dimensions (航空箱尺寸) | 460mm * 440mm * 340mm |
Technical Features & Principles
- 1470nm Wavelength: Features an excellent affinity for moisture absorption. Its gentle thermal energy precisely targets areas prone to sagging (such as the double chin, jawline, and nasolabial folds), utilizing mild thermal effects to firm and tighten localized tissue, delivering an instant lifting and contour-refining effect.
- 980nm Wavelength: Primarily targets the microcirculation layer. The thermal effect revitalizes the skin base and accelerates metabolism, while significantly enhancing the absorption of subsequent firming essences to restore elasticity and radiance.
- Fiber-Optic Coupling Technology: Delivers high-purity energy through a 3-meter premium optical fiber (400µm core diameter). The exceptionally uniform and stable energy distribution ensures a gentle, non-invasive experience that protects the skin surface completely.
- Flexible Multi-Mode Customization (Pulse & Continuous Modes): Equipped with both Pulse and Continuous modes. With precise adjustments available for pulse width (15ms–60ms) and frequency (1–9Hz), aesthetic professionals can easily customize parameters to suit each client’s skin sensitivity.
